This 1 Channel Laboratory Syringe Pump TYD offers precise, accurate and repeatable delivery of liquids from 0.037nl/min to 16.663ml/min. Each channel features a range of settings to allow tailored outputs to suit your needs. Stability, long life and quality are all guaranteed.
Features:
* Lab1st TYD series syringe pump adopts integrated table model design, 4.3-inch HD LCD touch screen display and operation, can assembly 1～10 plastic syringes or gas tight syringes, size range of syringe 10μl～140ml，flow range 0.037nl/min ~ 16.663ml/min.
* Use excellent control system and precision mechanical structure, linear travel accuracy<± 0.35%, multiple working modes are available,
* Powerful function It is very suitable for high precision micro-transmission of various fluids in scientific research and experiment.
* Drive screw fixation using high strength aviation bearing, compared with traditional copper sleeve bearing, the service life of the screw has been significantly improved, and the accuracy is higher.
* Strong Anti-EMI performance, continuous and stable operation under high voltage electrostatic field.
* RS485 communication, compatibility MODBUS protocol, automation control system can be composed of computer, PLC, single chip computer etc. multiple host computers.
Specifications:
* Flow range: 0.037nl/min～16.663ml/min
* Work mode: infuse, withdraw /withdraw/infuse, continuous mode
* Stroke of pump: 110mm
* Advance per micro step: 0.03125μm/μstep
* Linear speed: 0.2μm/min～30mm/min
* Linear resolution: 0.2μm/min
* Accuracy: error<±0.35%（>30% of pump stroke）
* Max rated linear force: >16kgf
* Thrust regulation: 1～100% arbitrary adjustable
* Syringe size: 10μl～60ml
* Syringe selection: built-in main manufacturers, the main model syringe to choose. Can use custom syringe, direct input syringe size and diameter
* Flow calibration: through the calibration procedure to obtain more accurate fluid volume
* Operation mode: touch screen + button
